The range of TX-MAX professional manual cutters are perfect for cutting all types of ceramic tiles. The high-performance multipoint breaker and rotating square system allows for quick and easy angle cuts (0° to 45°), especially when working with porcelain tiles. The cutters have up to 1,200 kg./ 2,646 lbs.of breaking power, making them excellent for use on extruded stoneware from 1/8" to 13/16" thick.
- Heavy duty, reinforced components
- 1,200 kg./ 2,646 lbs of breaking power
- Scoring head with extra-long aluminum slides and "self-lubricating" friction bushings
- Portable breaker with aluminum pressure pad has a plastic protector to avoid marking delicate surfaces
- Better visibility of the scoring and cutting zone
- Pressure pad is locked by a ratchet mechanism and is unlocked by a trigger, allowing one-handed scoring and breaking
- Pressure pad increases performance with both thin and thick materials
- Floating tables and supplementary arms increase stability for large sized tiles
- Rotating square with center pivot point and lateral end stop
- Handle with soft grip for better ergonomics and comfort
- Equipped with 8mm and 22mm EXTREME scoring wheels for highly precise tile scoring
- Includes carrying case (the 1250 model is equipped with wheels)
- 5 Year Warranty
| | TX-710 MAX | TX-1020 MAX | TX-1250 MAX |
|---|
| Ref. | 17910 | 17916 | 17922 |
| Cutting Length | 28" | 40-3/16" | 49-3/16" |
| Diagonally Cuts | 20" | 27-9/16" | 33-7/16" |
| Cutting Height | 1/8" - 13/16" | 1/8" - 13/16" | 1/8" - 13/16" |
| Weight | 29.3 lbs | 42.8 lbs | 57 lbs |
